Luna Classic

Condensing boilers

Heating only and combi condensing boilers. The perfect combination of advanced electronics and robust components

Residential

Wall Hung - compact

Luna Classic is the essential appliance for apartments or small homes. With compact dimensions, it can be installed in narrows spaces such as kitchen cabinets or laundries.

Excellent value for money, with control options ranging from the simplest to the most sophisticated.

Great care has been taken to encompass diverse end-user requirements. System customisation and optimisation are achievable without compromising ease of use.

Find a Dealer

Download Area

Characteristics

Models: 24, 28, 1.24
Compact dimensions (700x395x285) and light weight (28,5 kg)
Central flue (as traditional boilers), for easy and fast replacement
1:5 modulation to match the thermal output of the boiler to the demand of the building, optimising comfort levels. Reduced stress on components, lower noise level, and increased reliability
Stainless steal heat exchanger with large water passageway, greater thermal seasonal efficiency
New hydroblock reduces electrical consumption, and maximises DHW flow rate
Remote control Baxi Mago as optional

Features

Baxi Space

Advanced system control for a smart integration of different technologies. It offers a customized and efficient system tailored to meet all your needs and preferences

Digital Ready

It can be connected to BaxiMAGO, the WI-FI smart modulating thermostat, and Baxi service App. You can have your boiler always under control

Hydrogen Ready

Ready to work with a 20% hydrogen/natural gas blend, reducing gas consumption and environmental impact

Hybrid Ready

It facilitates the integration of other heating sources, such as heat pumps and solar thermal, simplifying the climate management of your home

1:5 Modulation

Modulation up to 1:5 reduces on-off cycles for improved efficiency and savings

Show Less

Technical Specification

MODELS		1.24	24	28
ErP data
Rated heat output	kW	24	20	24
Useful heat output at rated heat output and high temperature regime(2) P4	kW	24	20	24
Useful heat output at 30% of rated heat output and low temperature setting(1) P1	kW	8,1	6,7	8,1
Space heating – Seasonal energy efficiency ƞs	%	94	94	94
Useful efficiency at rated heat output and high temperature setting(2) ƞ4	%	88	88,2	88
Useful efficiency at 30% of rated heat output and low temperature setting(1) ƞ1	%	98,8	99	98,8
Sound power level, indoors LWA	dB	51	49	51
Declared load profile		-	XL	XL
Heat input/output
Rated heat input (Qn) for domestic hot water	kW	-	24,7	28,9
Rated heat input (Qn) for heating	kW	24,7	20,6	24,7
Rated heat output (Pn) for domestic hot water	kW	-	24	28
Rated heat output (Pn) 80/60 °C for heating	kW	24	20	20
Rated heat output (Pn) 50/30 °C for heating	kW	26,1	21,8	26,1
Heating circuit
Temperature range for heating circuit	°C	25/80	25/80	25/80
Water capacity of expansion vessel	l	7	7	7
Domestic water circuit
Temperature range for domestic water circuit	°C	35/60	35/60	35/60
Domestic water production with ΔT = 25 °C	l/min	-	13,8	16,1
Domestic water production with ΔT = 35 °C	l/min	-	9,8	11,5
Combustion
Diameter of separate discharge pipes	mm	80/80	80/80	80/80
Diameter of coaxial discharge pipes	mm	60/100	60/100	60/100
Nitrogen oxide emissions NOx	mg/kWh	30	32	30
Flue gas mass flow rate (max)	kg/sec	0,013	0,011	0,013
Flue gas mass flow rate (min)	kg/sec	0,003	0,002	0,003
Electrical characteristics
Power supply voltage	V	230	230	230
Power supply frequency	Hz	50	50	50
Rated electric power	W	88	78	88
Dimensions
Humidity protection rating (EN 60529)	IP	X5D	X5D	X5D
Net weight	kg	29	28,5	30
Dimensions (height/width/depth)	mm	700/395/285	700/395/285	700/395/285

(1) Low temperature: return temperature (at boiler inlet) for condensing boilers 30°C, for low temperature boilers 37°C and for other heaters 50°C.
(2) High temperature setting means 60 °C return temperature at boiler inlet and 80 °C flow temperature at boiler outlet.
