Auriga A

Heat pumps
Auriga A

Heat Pumps

Air-source monobloc heat pumps

Residential

Monobloc

Auriga is an all-in-one monobloc heat pump, operating with R32 refrigerant fluid, for heating and cooling.

It integrates all components into a single outdoor unit, simplifying installation and maintenance.

Conceived for new building with enhanced insulation and modern heating and cooling systems or refurbishment projects with any type of low/medium temperature systems: fan coils, underfloor heating, or low temperature high efficiency radiators.

Auriga can be combined with a Baxi boiler to obtain a full hybrid system or with an indirect tank for hot water production.

Find a Dealer

Download Area

Characteristics

Models: 4M, 6M, 8M, 10M, 12M/T, 16M/T
Range from 4 to 16 kW
Complete hydraulic equipment pre-assembled to save installation time
Noise level equivalent to normal conversation,suitable for installation in high-density residential areas
Auriga heat pumps can be installed in cascade (up to 6 units)
Intelligent defrosting via the monitoring of room temperature, refrigerant
temperature, water temperature and operating mode
Wide operation ratio DC inverter compressor, low GWP refrigerant (R32)
Modbus integration

Features

Hybrid Ready

It facilitates the integration of other heating sources, simplifying the climate management of your home

Keymark

The product follows the European Standards, and it is marked with Keymark

Smart Grid

It matches the supply and demand of electricity in real time, saving money on the energy bill

65°C

This product can produce hot water up to 65°C, without any other accessories required (such as immersion resistance)

R32

R32 has a low GWP (675), meaning it has a very limited impact on the environment

Heating, cooling and DHW

A year-round comfort: you can heat your home in winter and cool it in summer, with one sole product. This appliance also allows the domestic hot water production

Show Less

Technical Specification

MODELS		4M	6M	8M	10M	12M	16M	12T	16T
ErP data
Nominal heating capacity (1)	kW	4,2	6,35	8,4	10	12,1	15,9	12,1	15,9
COP (1)		5,1	4,95	5,15	4,95	4,95	4,5	4,95	4,5
Nominal cooling output (2)	kW	4,5	6,5	8,3	9,9	12	14,2	12	14,2
EER (2)		5,5	4,8	5,05	4,55	3,95	3,61	3,95	3,61
Performance
Refrigerant fluid R32 / Equivalent CO2	kg/tCO2e	1,40/0,94	1,40/0,94	1,40/0,94	1,40/0,94	1,75/1,18	1,75/1,18	1,75/1,18	1,75/1,18
Sound power according to EN 12102: water temperature 55°C and outdoor air temperature 7°C	dB(A)	55	58	59	60	65	68	65	68
Sound pressure - Average sound pressure, at 1 meter distance, in free field on a reflective surface	dB(A)	45	47,5	48,5	50,5	53	57,5	53,5	58
Operating limits
Heating mode - Outdoor air temperature min/max	°C	-25/+35	-25/+35	-25/+35	-25/+35	-25/+35	-25/+35	-25/+35	-25/+35
Heating mode - Water temperature min/max	°C	+12/+65	+12/+65	+12/+65	+12/+65	+12/+65	+12/+65	+12/+65	+12/+65
Cooling mode - Outdoor air temperature min/max	°C	-5/+43	-5/+43	-5/+43	-5/+43	-5/+43	-5/+43	-5/+43	-5/+43
Cooling mode - Water temperature min/max	°C	+5/-25	+5/-25	+5/-25	+5/-25	+5/-25	+5/-25	+5/-25	+5/-25
Dimensions
System water content - min.	l	25	25	25	25	40	40	40	40
Dimensions (hxwxd)	mm	718x1295x429	718x1295x429	1385x865x526	1385x865x526	1385x865x526	1385x865x526	1385x865x526	1385x865x526
Empty weight	kg	98	98	121	121	144	144	160	160
Power supply	V/Ph/Hz	230/1/50	230/1/50	230/1/50	230/1/50	230/1/50	230/1/50	400/3/50	400/3/50

(1) Outdoor air temperature 7°C - 87% R.H., water temperature 30/35°C - EN 14511

(2) Outdoor air temperature 35°C, water temperature 18°C - EN 14511

Download Area

Energy label

Installation, User and Service Manual

Leaflet
