PBM2-i

Heat pumps
PBM2-i

Heat Pumps

Commercial air-source monobloc heat pumps

Commercial

Monobloc

PBM2-i heat pumps are equipped with a high modulation range inverter compressor.

Compact dimensions make it the ideal solution for commercial and residential applications with centralised systems.

Easy installation and service: all hydraulic components are supplied with the heat pump, frontal access, and rear connections.

Find a Dealer

Download Area

Characteristics

Models: 20, 25, 30, 35, 42, 50
Small footprint (1160x500 mm area, up to the 25 kW model)
Low noise levels
Wide operating range
Suitable for radiant terminal systems, fan coils and mixed systems
Intelligent defrosting via the monitoring of room temperature, refrigerant
temperature, water temperature and operating mode
Wide operation ratio DC inverter compressor
Modbus integration
R410A refrigerant

Features

Hybrid Ready

It facilitates the integration of other heating sources, such as heat pumps and solar thermal, simplifying the climate management of your home

Heating, cooling and DHW

A year-round comfort: you can heat your home in winter and cool it in summer, with one sole product. This appliance also allows the domestic hot water production

Technical Specification

MODELS		50	42	35	30	25	20
ErP data
Nominal heating capacity (1)	kW	49,40	41,80	35,70	30,00	25,80	21,50
COP (1)		4,22	4,22	4,23	4,27	4,30	4,30
Nominal cooling output (2)	kW	42,3	35,9	30,5	25,8	22,4	19
EER (2)		3,16	3,18	3,27	3,23	3,11	3,17
System and Performace
Refrigerant gas		R410A	R410A	R410A	R410A	R410A	R410A
Refrigerant gas load	kg	6,1	6	5,7	5,5	4,2	4,1
Sound power	dB(A)	78	78	78	76	75	74
System water content - min.	l	120	105	85	70	61	51
Plug-fan flow	m³/h
Dimensions
Empty weight	kg	283	269	239	224	201	199
Dimensions (hxwxd)	mm	1275x1855x1005	1275x1855x1005	1275x1855x1005	1275x1855x1005	1270x1167x503	1270x1167x503
Electrical characteristics
Power supply	V/Ph/Hz	400/3/50	400/3/50	400/3/50	400/3/50	400/3/50	400/3/50
